ARaymond 201113000

ARaymond Network Tinnerman®
Use condition dimensions (mm)
D1 – Tube/Cable Diameter
2 – 40
F1 – Panel Thickness
0.8 – 1.3
R1 – Hole Diameter
6.5 – 6.7
Product dimensions (mm)
b – Width
16
bt1 – Tie Width
6
h – Height
168
l – Length
16
r1 – Contact Diameter
16
