ARaymond 132681000

ARaymond Network Tinnerman®
Use condition dimensions (mm)
B1 – Width of Hole
7.9 – 8.1
F1 – Panel Thickness
2.6 – 2.8
H1 – Stud Height
15.9 – 16.1
L1 – Length of Hole
15
X1 – Length of Stud
10 – 11
Y1 – Width of Stud
1.7 – 2.1
Product dimensions (mm)
b – Width
12.5
b1 – Width
12
h – Height
16.5
ha – Height above the support
0
hb – Height below support
15.5
l – Length
9.45
s – Product Thickness
0.5
