ARaymond 081794000

ARaymond Network Tinnerman®
Use condition dimensions (mm)
D1 – Tube/Cable Diameter
35 – 38
F1 – Panel Thickness
0.8 – 2
R1 – Hole Diameter
6.5 – 6.7
Product dimensions (mm)
b – Width
12
h – Height
64
h1 – Height
31
hb – Height below support
6.5
l – Length
42.6
r1 – Contact Diameter
20
