ARaymond 054177001

ARaymond Network Tinnerman®
Use condition dimensions (mm)
D1 – Tube/Cable Diameter
4.8 – 8
H1 – Stud Height
14
Z1 – Stud Diameter
5
S1 – Screw/Thread
T5 Stud
Product dimensions (mm)
b – Width
10
h – Height
24.5
l – Length
28.5
